Automatic Extinguishers

Automatic Extinguishers
Product Introduction:
● High-efficiency automatic fire suppression
● Reliable stainless steel construction
● Automatic activation mechanism
● Resistant to extreme environments
● Space-saving hanging design
● Easy installation and maintenance
Send Inquiry
Description
Technical Parameters
Product Description



Zoesky's automatic extinguisher is a fire suppression device specifically designed for emergency situations.

Zoesky's automatic hanging fire extinguisher is a highly efficient, reliable, and safe device for automatic fire suppression.



Product Specification



Product name:

Automatic Hanging Stainless Steel Extinguisher

Product code:

SS01-356-300

SS01-3510-300

SS01-3515-300

SS01-3520-300

Product photo:

Automatic extinguisher001

Automatic extinguisher 001

Automatic ext001

Automatic Extinguishers 001

Volume(L):

6

10

15

20

Out-diameter(mm):

Φ295

Φ337

Φ392

Φ392

Cylinder high(mm):

215

239

285

343.5

Filling charge :

Powder / Foam / Water

Powder / Foam / Water

Powder / Foam / Water

Powder / Foam / Water

Temperature:

-10℃+50℃

-10℃+50℃

-10℃+50℃

-10℃+50℃

Material :

SUS304

SUS304

SUS304

SUS304

Packing:

1pc/carton

1pc/carton

1pc/carton

1pc/carton



Automatic extinguishers: Efficient fire suppression



The automatic fire extinguisher is a widely utilized fire-suppression device that automatically triggers when ambient temperature surpasses its preset activation level in the event of a fire.
Upon activation, it dispenses an extinguishing agent that swiftly covers the fire source, efficiently containing the spread of the blaze and promptly extinguishing the fire, finally safeguarding human lives and property.



What types of fires are suitable for automatic extinguishers?



The types of fires suitable for automatic fire extinguishing devices vary depending on the type of extinguishing agent contained within the extinguisher.
● As an example, automatic foam extinguishers are specifically designed to tackle Class A and Class B fires.
● Class A fires refer to those caused by the combustion of solid organic materials, such as wood, paper, and cotton fabrics.
● Class B fires refer to those caused by the combustion of flammable liquids, including gasoline, diesel, kerosene, and other fats and oils.



Ideal Uses



The application scope and venues for the Zoesky's automatic fire extinguishers are extensive. These include:
1.Crowded venues such as shopping malls, supermarkets, hotels, and restaurants.
2.Public buildings like hospitals and libraries.
3. Industrial production environments such as factories and warehouses.



● Regardless of the type of fire, automatic fire extinguishers are suitable for the following conditions:
(1) The initial stage of a fire.
(2) Surface fires.



Maybe you want to know?



The color of the glass beads in the sprinkler indicates a specific rupture temperature.

Glass beads color of the sprinkler

Rupture temperature

Application scenario

Orange

57℃

General Use

Red

68℃

General Use

Yellow

79℃

Kitchen

Green

93℃

Hot Water Applications

Blue

141℃

Specialty Warehouses

Violet

182℃

Specialty Warehouses



For example, when the ambient temperature reaches or exceeds 68 degrees Celsius, the red glass beads rupture.

The fire extinguisher will automatically release the extinguishing agent, effectively suppressing the spread of the fire.



Product Material



Zoesky's automatic fire extinguishers are made of high-quality stainless steel, which is excellent in corrosion resistance, high-temperature resistance, and compression deformation resistance.
Even in extreme environments, it can maintain stable performance and ensure effective fire suppression.
It is resistant to dirt accumulation, facilitating easier cleaning and maintenance.
With its durability and a reasonable structural design, this fire extinguisher effectively reduces replacement costs, ensuring long-term cost-efficiency.


Installation and maintenance



1.Features and considerations for installing automatic fire extinguishers:
The installation and maintenance of Zoesky's automatic fire extinguishers is extremely convenient, significantly saving customers time and effort.
① The hanging automatic fire extinguisher can be easily fixed on walls, ceilings, and other locations.
② It does not occupy ground space, thus realizing the rational use of space.
③ The fire extinguisher should be placed in an easily accessible place, avoiding collisions with people or other objects.
④Correct hanging methods for fire extinguishers are crucial for safeguarding the lives and property of personnel.
⑤ It is essential to select appropriate hanging positions based on the actual needs of different locations and to provide corresponding identification and marking.



2.Maintenance
①Please regularly check the remaining amount of extinguishing agent to ensure the equipment is in good working condition.
②Please regularly calibrate and test the automatic fire extinguisher to maintain its sensitivity.

Notes: Please follow the product manual and relevant fire safety regulations during installation and maintenance to ensure operational safety.
